BLR/SG 系列试液镜

描述

BLR/SGN 型视液镜用于制冷、空调装置的液体管路上，用来指示制冷剂的流动状况、制冷剂中的含水量及油分离器回油管路中润滑油的流动状况。它带有一潮湿指示器，通过改变颜色来指示制冷剂中的含水量。使用改性PTFE密封材料，适用于多种制冷剂及冷冻油，又具有好的密封性能。并且采用防爆压接的结构，观察窗清晰而安全。

特点

用于HCFC/HFC制冷剂

指示系统中过高的含水量制冷剂液体无过冷度指示

制冷剂充注量不足指示

焊口、螺口两种接口

技术参数

Model	Connection	A	B	?C	?D	E	F	L	S	Thread M	Weight (g)
BLR/SG-014S	1/4 ODF	8.5	14.5	26.5	6.5	7	27	100	14	-----	96
BLR/SG-014	1/4 SAE				---	---	14	64		7/16-20UNF	100
BLR/SG-038S	3/8 ODF				10.1	8	36	118		-----	105
BLR/SG-038	3/8 SAE				---	---	17	70		5/8-18UNF	110
BLR/SG-012S	1/2 ODF	11.5	16.5		12.8	10	46	144	19	-----	150
BLR/SG-012	1/2 SAE	11.5	16.5		---	---	19	78	19	3/4-16UNF	165
BLR/SG-058S	5/8 ODF	13	18		16.1	14	49	150	22	-----	185
BLR/SG-058	5/8 SAE	13	18		---	---	20	78	22	7/8-14UNF	188
BLR/SG-034S	3/4 ODF	14	20	31.5	19.1	16	51	166	24	-----	240
BLR/SG-034	3/4 SAE	14	20		---	---	23	94	24	1-1/16-14UNF	285
BLR/SG-078S	7/8 ODF	15.5	21.5		22.3	17	54	172	27	-----	290

Item	Model	Connection
Double Head Sight Glass with Solder Connection	BLR/DSGN 22	7/8"
	BLR/DSGN-28	1-1/8"
	BLR/DSGN-35	1-3/8"
	BLR/DSGN-42	1-5/8"
	BLR/DSGN-54	2-1/8"
	BLR/DSGN-66	2-5/8"
Male & Female Connection Combined Sight Glass(F:Means Male Flare M:Means o Ring Connection)	BLR/SGN-038FM	3/8
	BLR/SGN-012FM	1/2
O ring & Female SAE Combined Sight Glasss(F:Means Male Flare M:Means o Ring Connection)	BLR/SGN-9/16"FMO	9/16"Female SAE
	BLR/SGN-11/16"FMO	11/16"Female SAE
	BLR/SGN-3/8"FMO	3/8 Female SAE
	BLR/SGN-1/2"FMO	1/2 Female SAE
Sight Glass Screw Head for Sight Glass	BLR/SGNH-1/4	1/4
	BLR/SGNH-3/8	3/8
	BLR/SGNH-1/2	1/2
	BLR/SGNH-5/8	5/8
	BLR/SGNH-3/4	3/4
Sight Glass Screw Head for Receiver & Oil Reservoir	BLR/SGN-1/2 NPT	1/2" NPT SW27
	BLR/SGN-3/4 NPT	3/4" NPT SW30
	BLR/SGN-G1/2	G1/2"
	BLR/SGN-G3/4	G3/4"


B- VALVES AND CONTROLLERS_23.pdf
